GTA San Andreas object

OC_FLATS_GND09_SFS object ID 10421

Object ID: 10421
Model name: OC_FLATS_GND09_SFS
Texture file (TXD): oc_flats_gnd_sfs
Draw distance: 120
Defined in: SFs.ide
Flags: 0
Placed in the world: 1 time

MTA:SA code

Copy a line into your script. The lines use the first place the game puts this object. Removing a building also needs its far-away (LOD) models removed, as the lines below it do. Removing a world model does not remove its occlusions, so nearby parts of the map can disappear; the MTA wiki suggests setOcclusionsEnabled(false).

local obj = createObject(10421, -2782.81, 74.66, 7.28)

removeWorldModel(10421, 10, -2782.81, 74.66, 7.28) -- removes the one at Ocean Flats, San Fierro

removeWorldModel(10579, 10, -2782.81, 74.66, 7.28) -- its far-away model LODFLATSGND02_SFS

engineGetModelNameFromID(10421) -- "OC_FLATS_GND09_SFS" (client side)

Where the game places it

X, Y and Z of each place, with the zone name the game gives it. Map opens the coordinates map on that spot.

X, Y, Z	Zone
-2782.81, 74.66, 7.28	Ocean Flats, San Fierro	Map

Its far-away models

The low-detail (LOD) models the game draws instead of this one from far away.

10579LODFLATSGND02_SFS

Same texture file

22 other objects use oc_flats_gnd_sfs.

San Fierro · All objects, page 77 · Search all 14,259 objects · Coordinates map

Where this comes from

GTA San Andreas SFs.ide (the definition), the map IPL files and the stream IPLs in gta3.img (the places), and info.zon (zone names), read from an installed copy of the game. The file list is the game's own gta.dat.
The picture: drawn on 3 October 2026 from this model and its texture file in an installed copy of the game. It is lit plainly and the shade the model stores is brightened, so the game can show it darker; the camera looks at the side with the most to see. Only the picture is hosted, not the model or its textures.
MTA wiki: createObject
MTA wiki: removeWorldModel
MTA wiki: engineGetModelNameFromID

Checked on 29 September 2026.
